PolarFlip is currently in development. Expected availability: 2026.

PolarFlip — RH / LH Circular Phasing Box

PolarFlip is a precision phasing device that accepts two matched linear antenna inputs and produces four simultaneous outputs: ANT1 (linear), ANT2 (linear), RHCP (Right-Hand Circular), and LHCP (Left-Hand Circular). It is designed for HF low-band and NVIS receive systems where polarization behavior dictates signal strength and stability.

Key benefit:
Instant access to both hands of circular polarization — no relays, no switching delay, and both linear channels available for reference or diversity.

Main Features

  • Four simultaneous outputs: ANT1, ANT2, RHCP, LHCP
  • Transforms two linear antenna channels into both circular hands
  • Improves SNR in conditions with Faraday rotation or polarization mismatch
  • Low-loss hybrid network with high isolation between RH and LH
  • Compact and shack-friendly phasing enclosure

Applications

  • Low-band HF receiving (160 m to 30 m)
  • NVIS systems where ionospheric rotation causes fading
  • Diversity reception with linear channels plus both circular channels
  • Contest field stations, portable ops, and DXpeditions

Technical Specifications

Note: Specifications are preliminary and will be updated after final validation.
Parameter Value
Supported Bands 160 m to 30 m (receive only)
Inputs 2 × matched linear antenna channels
Outputs ANT1, ANT2, RHCP, LHCP (simultaneous)
Insertion Loss To be announced
RH/LH Isolation Target >10 dB (final value TBA)
Power Requirements None (passive)
Enclosure Final enclosure design to be disclosed

Package Includes

  • 1 × PolarFlip phasing box
  • Mounting hardware
  • User guide
Development Status:
Under active testing. Public release planned for 2026.
